--- title: Optimised Filtration of Pigmented Digital Ink description: The importance of correct filter selection for digital ink image: https://www.amazonfilters.com/hubfs/amz01/Pages/Industry/digital-inks.jpg --- [+44 (0) 1276 670600](tel:+44%20(0)%201276%20670600) [![Amazon Filters Logo](https://www.amazonfilters.com/hubfs/amz01/Global/Logos/amazon_filters_logo_color.svg) ](https://www.amazonfilters.com) Products [All products](https://www.amazonfilters.com/products) [Filter cartridges & capsules](https://www.amazonfilters.com/products/filter-cartridges-and-capsules) [Filter housings](https://www.amazonfilters.com/products/filter-housings) [Custom filter housings](https://www.amazonfilters.com/products/custom-filter-housings) [Retrofits](https://www.amazonfilters.com/products/replacement-retrofit-filters) [OEM](https://www.amazonfilters.com/products/oem-filters) Applications [Pharmaceuticals and healthcare](https://www.amazonfilters.com/industry/pharmaceutical-filters) [Energy](https://www.amazonfilters.com/industry/energy/) [Water](https://www.amazonfilters.com/industry/industrial-water-filtration) [Food and beverage](https://www.amazonfilters.com/industry/food-and-beverage-filtration) [Chemicals & coatings](https://www.amazonfilters.com/industry/chemical-filters) [Case Studies](https://www.amazonfilters.com/case-study) Company [About Us](https://www.amazonfilters.com/about-us) [Compliance](https://www.amazonfilters.com/compliance) [Contact](https://www.amazonfilters.com/contact-us) [Careers](https://www.amazonfilterscareers.com/) [News](https://www.amazonfilters.com/company-information/news) Resources [Blog](https://www.amazonfilters.com/blog) [Resources](https://www.amazonfilters.com/resources) [Application Notes Library](https://www.amazonfilters.com/application-notes/) [Sustainable Polypropylene](https://www.amazonfilters.com/renewable-polypropylene-p) [ Talk to Sales ](https://cta-service-cms2.hubspot.com/web-interactives/public/v1/track/click?encryptedPayload=AVxigLL0Oq4lAJH9H08QO8yJnKOTdE7ZJ1dhnK%2BQrtluhANRS%2BeIZYDyaxLqPwrngRYLo%2B9fsdYVk6P6PEstK%2FUhtwJGdY20B0vzkGf4dwdp6TPKqjutDLD7QyjnLHzlPVxiQ%2B7AlmYkM%2BQ6Um8WgwHEtAnSnBv5PFvYevdyVlcVkj4mvdClOBE%2BMMnPWj3aYKU%3D&portalId=6888762) [ Get a Quote ](https://cta-service-cms2.hubspot.com/web-interactives/public/v1/track/click?encryptedPayload=AVxigLJROGIbyd30Lwhh%2FYtr45fh49c69UGdbjroNByqjaHkwQnD1dJegkKPeUL5Ed3mtwVjwJmuPIFOAuo%2Bh6%2Fed7YyhCeHNFTFOhOTJwj3zgr3f2KVzf1cDTArQklXAfGWVTjH4UrPuxcxV8GiteJS%2FScYhfZbIXuFDZb33Lh0WVHl7ePOfgH0M9FTZSIb&portalId=6888762) [![Amazon Filters Logo](https://www.amazonfilters.com/hubfs/amz01/Global/Logos/amazon_filters_logo_color.svg) ](https://www.amazonfilters.com) ![Search icon](https://www.amazonfilters.com/hubfs/amz01/Global/Icons/search_icon_large.svg) Products [All products](https://www.amazonfilters.com/products) [Filter cartridges & capsules](https://www.amazonfilters.com/products/filter-cartridges-and-capsules) [Filter housings](https://www.amazonfilters.com/products/filter-housings) [Custom filter housings](https://www.amazonfilters.com/products/custom-filter-housings) [Retrofits](https://www.amazonfilters.com/products/replacement-retrofit-filters) [OEM](https://www.amazonfilters.com/products/oem-filters) Applications [Pharmaceuticals and healthcare](https://www.amazonfilters.com/industry/pharmaceutical-filters) [Energy](https://www.amazonfilters.com/industry/energy/) [Water](https://www.amazonfilters.com/industry/industrial-water-filtration) [Food and beverage](https://www.amazonfilters.com/industry/food-and-beverage-filtration) [Chemicals & coatings](https://www.amazonfilters.com/industry/chemical-filters) [Case Studies](https://www.amazonfilters.com/case-study) Company [About Us](https://www.amazonfilters.com/about-us) [Compliance](https://www.amazonfilters.com/compliance) [Contact](https://www.amazonfilters.com/contact-us) [Careers](https://www.amazonfilterscareers.com/) [News](https://www.amazonfilters.com/company-information/news) Resources [Blog](https://www.amazonfilters.com/blog) [Resources](https://www.amazonfilters.com/resources) [Application Notes Library](https://www.amazonfilters.com/application-notes/) [Sustainable Polypropylene](https://www.amazonfilters.com/renewable-polypropylene-p) [ Talk to Sales ](https://cta-service-cms2.hubspot.com/web-interactives/public/v1/track/click?encryptedPayload=AVxigLL0Oq4lAJH9H08QO8yJnKOTdE7ZJ1dhnK%2BQrtluhANRS%2BeIZYDyaxLqPwrngRYLo%2B9fsdYVk6P6PEstK%2FUhtwJGdY20B0vzkGf4dwdp6TPKqjutDLD7QyjnLHzlPVxiQ%2B7AlmYkM%2BQ6Um8WgwHEtAnSnBv5PFvYevdyVlcVkj4mvdClOBE%2BMMnPWj3aYKU%3D&portalId=6888762) [ Get a Quote ](https://cta-service-cms2.hubspot.com/web-interactives/public/v1/track/click?encryptedPayload=AVxigLJROGIbyd30Lwhh%2FYtr45fh49c69UGdbjroNByqjaHkwQnD1dJegkKPeUL5Ed3mtwVjwJmuPIFOAuo%2Bh6%2Fed7YyhCeHNFTFOhOTJwj3zgr3f2KVzf1cDTArQklXAfGWVTjH4UrPuxcxV8GiteJS%2FScYhfZbIXuFDZb33Lh0WVHl7ePOfgH0M9FTZSIb&portalId=6888762) [+44 (0) 1276 670600](tel:+44%20(0)%201276%20670600) Case study # Optimised Filtration of Pigmented Digital Ink ![](https://www.amazonfilters.com/hubfs/case-studies/tag-icon@3x.svg) Chemicals & Coatings #### Product **SupaPleat Plus Ink** #### Client Global Digital Ink Manufacturer #### Application Filtration of Pigmented Digital Ink #### Location UK #### Value Added Prevention of printer nozzle blockage #### Sector Chemicals and Coatings ## Summary As the technology in industrial inkjet printing advances towards higher definition, with drop sizes down to 1.0pl, the size of the print head nozzle continues to reduce. This poses increased challenges to the bulk ink manufacturers as they try to develop optimised filtration systems to prevent nozzle blockage while not adversely affecting the manufacturing cost. One global manufacturer of pigment based UV curable inks began to receive reports of reduced or inconsistent jetting performance on piezo heads from its customers using wide format printers. This can have major cost implications including maintenance downtime, rework, and potential replacement of expensive print heads. Because of our experience and expertise developing [high-quality filtration solutions for chemicals and coatings](https://www.amazonfilters.com/industry/chemical-filters), Amazon Filters were chosen to work with this global manufacturer. The brief: to develop a new filter to ensure the removal of the contamination whilst maximising the transmission of the colour pigments. Following the introduction of the new filter in production, the customers jetting sustainability issues have been resolved. ## The Problem**  ** Advances in inkjet technology, such as Miniature Electro Mechanical Systems (MEMS), are driving the increased specification of bulk digital ink with respect to tighter classification and particle retention. It has been reported that to prevent nozzle blockage, particulate in the ink should be 100 times smaller than the nozzle diameter. With nozzle diameter’s ranging from 10-50 microns this ideal is not always possible especially with milled pigments in the range of 150-200nm. Unwanted particulate, agglomerate and gels can originate from a number of sources. Raw materials suppliers, gels generated due to heat excursions during the blending of the formulations, accidental exposure to light that initiate polymerisation as well as poor maintenance of print heads all contribute. Preventing jetting sustainability issues due to nozzle blockage is a balance between maximising the pigment transmission while removing as much of the extraneous contamination as possible. ## A Collaborative Approach Ideally the ink manufacturer would provide details of the ink formulation and the filter supplier would provide the appropriate filter. In reality the complexity of todays’ ink formulations means that a collaborative approach is needed to co-develop the most appropriate filter and ensure an optimised solution. Amazon worked closely with the customer, supplying configurations that were initially evaluated using jetting sustainability trials on Cyan ink. The results were then used to improve the filter performance by modifying the configuration of the filtration layers. Final approval of the filter performance was achieved using particulate analysis of the ink post filtration. ![jetting image digital ink](https://www.amazonfilters.com/hs-fs/hubfs/jetting%20image%20digital%20ink.jpg?width=522&height=318&name=jetting%20image%20digital%20ink.jpg) Fig 1: Jetting patterns showing drop out in individual nozzles (vertical white lines) ## Jet Sustainability To qualify the suitability of the ink quality a jetting sustainability trial was conducted on a 800kg batch of Cyan UV curable pigment based ink. This involved continuous jetting for 1 minute and monitoring the number of nozzles dropping out over time. This is not something that would happen in the actual printing process but it gives a good indication of potential problems that could occur for the customer. The image shows some representative jetting maps from the initial prototype filters compared to the original supplier. ## **Throughput and Filtrate Quality** In conjunction with the jetting tests the flowrate decay was measured to ensure full batches could be processed in the required time. The profiles indicate the significant variation in throughput dependant of filtration media type and configuration. It also highlighted how two filters with the same blocking characteristics can give significantly different filtrate quality. The higher the percentage of small particles the better. The measured filtrate quality could also be directly linked to the jetting performance images produced, giving confidence that a verification of product performance based on filtrate quality, would lead to the resolution of jetting sustainability issues for the customer. ![ink quality](https://www.amazonfilters.com/hs-fs/hubfs/ink%20quality.jpg?width=591&height=333&name=ink%20quality.jpg) ## FINAL DESIGN AND VERIFICATION A total of eight filter media combinations were eventually tested to obtain the most appropriate version. Configuration improvements included use of higher loft meltblown materials on the upstream side to maximise the capture of gels and guarantee processing times. Analysis of the viscosity profiles for the various ink colours, Cyan, Magenta, and Black resulted in additional development work to improve the separation of pleats to maximise flow and throughput. Particle size analysis was used to confirm the performance of the final variant. The ink manufacturer decided to concentrate on the filtrate quality below 2.5 microns as a means of verification as this had the most influence on jetting performance. ![efficiency table for digital ink SupaPLeat Ink](https://www.amazonfilters.com/hs-fs/hubfs/efficiency%20table%20for%20digital%20ink%20SupaPLeat%20Ink.png?width=724&height=373&name=efficiency%20table%20for%20digital%20ink%20SupaPLeat%20Ink.png) The measured filtrate quality demonstrates a significant improvement using the new filter design. There is between a 34% and 38% reduction in the quantity of particulate in conjunction with a significant reduction in the number of larger particles as highlighted in the table above. Displaying the data in a different way more clearly demonstrates the reduction in larger particles in the filtered ink which were causing the jetting issues. ![efficiency graph digtal ink-1](https://www.amazonfilters.com/hs-fs/hubfs/efficiency%20graph%20digtal%20ink-1.png?width=704&height=508&name=efficiency%20graph%20digtal%20ink-1.png) The graph also highlights the often, erroneous nature of assigned micron ratings for filters. The complex nature of inkjet formulations and the presence of specific contaminants such as microgels means that traditional methods of assigning efficiency using, for example ACFTD, are not always relevant to the actual process. For this reason Amazon Filters have assigned grades to the [SupaPleat Plus Ink range](https://www.amazonfilters.com/products/filter-cartridges-and-capsules/pleated-filters/supapleat-plus-ink) rather than micron ratings. These grades are linked to the ink quality requirements of various printhead technologies and can be used as a starting point for filter evaluation.   ## Conclusion Through close collaboration with the ink manufacturer and an iterative approach to product design based on customer feedback, the quality and consistency of the digital ink has been substantially improved resulting in the elimination of jetting issues and cost saving due to the elimination of down time on the printer. As a result of the work conducted during this project, a range of SupaPleat Plus Ink filters have been developed and introduced to complement the existing portfolio for ink filtration from the [SupaSpun](https://www.amazonfilters.com/supaspun-ii) and** **[SupaPore](https://www.amazonfilters.com/products/filter-cartridges-and-capsules/capsule-filters/supapore-pleated-depth-capsules) range. All these filters can be incorporated into the SupaClean range of housings to facilitate the clean change of filters whilst minimising Heath & Safety issues associated with solvent based inks. ![shutterstock_2374700419 (1)](https://www.amazonfilters.com/hs-fs/hubfs/shutterstock_2374700419%20(1).jpg?width=500&height=285&name=shutterstock_2374700419%20(1).jpg) - **The correct filtration solution can prevent costly printhead failures ** - **Working directly with the customer and sharing technical data is critical in developing the correct filtration solution** - **The SupaPleat Plus Ink range has been specifically designed for digital ink filtration** ## Let's **get started** We'll make sure you're getting the best out of your filtration system [ Talk to sales ](https://www.amazonfilters.com/talk-to-sales) Applications - [Pharma and healthcare](https://www.amazonfilters.com/industry/pharmaceuticals-and-healthcare) - [Energy](https://www.amazonfilters.com/industry/energy/) - [Water](https://www.amazonfilters.com/industry/water-filtration) - [Food and beverage](https://www.amazonfilters.com/industry/food-and-beverage) - [Chemicals and coatings](https://www.amazonfilters.com/industry/chemicals-coatings) Products - [All products](https://www.amazonfilters.com/products) - [Filter cartridges & capsules](https://www.amazonfilters.com/products/filter-cartridges-and-capsules) - [Filter housings](https://www.amazonfilters.com/products/filter-housings) - [Customised filter housings and skids ](https://www.amazonfilters.com/products/customised-filter-housing-and-skids) - [Retrofits](https://www.amazonfilters.com/replacement-retrofit-filters) - [OEM](https://www.amazonfilters.com/industry/oem-filters)   Legal - [Privacy policy](https://www.amazonfilters.com/legal/privacy-policy) - [Copyright](https://www.amazonfilters.com/legal/copyright) - [Trademark](https://www.amazonfilters.com/legal/trademark) - [Disclaimer](https://www.amazonfilters.com/legal/disclaimer) - [Conditions of sale](https://www.amazonfilters.com/legal/conditions-of-sale) About - [About us](https://www.amazonfilters.com/about-us) - [Global network](https://www.amazonfilters.com/our-global-network) - [Careers](https://www.amazonfilters.com/company-information/careers) - [Compliance](https://www.amazonfilters.com/compliance) - [Blog](https://www.amazonfilters.com/blog) - [News](https://www.amazonfilters.com/company-information/news) - [Contact us](https://www.amazonfilters.com/contact-us) Contact Amazon Filters Ltd. Albany Park Estate, Frimley Road Camberley, Surrey GU16 7PG, England [+44 (0) 1276 670600](tel:%3Cp%3EContact%3C/p%3E%20%3Cp%3EAmazon%20Filters%20Ltd.%3Cbr%3EAlbany%20Park%20Estate,%20Frimley%20Road%3Cbr%3ECamberley,%20Surrey%3Cbr%3EGU16%207PG,%20England%3C/p%3E) ![Amazon Filters Footer Logo (Grey)](https://www.amazonfilters.com/hubfs/amz01/Global/Logos/amazon_filters_logo_grey.svg) ©2026 Amazon Filters Ltd. All rights reserved .   [ Cookie Settings ](https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink#) Website by [Blend](https://www.blendb2b.com/) ![](https://px.ads.linkedin.com/collect/?pid=2495516&fmt=gif) ```json { "@context" : "https://schema.org", "@id" : "https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink#webpage", "@type" : "WebPage", "description" : "The importance of correct filter selection for digital ink", "image" : "https://www.amazonfilters.com/hubfs/amz01/Pages/Industry/digital-inks.jpg", "isPartOf" : { "@id" : "#website" }, "mainEntity" : { "@id" : "https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink#casestudy" }, "name" : "Optimised Filtration of Pigmented Digital Ink", "url" : "https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink" } ``` ```json { "@context" : "https://schema.org", "@id" : "#breadcrumb", "@type" : "BreadcrumbList", "itemListElement" : [ { "@type" : "ListItem", "item" : { "@id" : "https://www.amazonfilters.com/", "name" : "Home" }, "position" : 1 }, { "@type" : "ListItem", "item" : { "@id" : "https://www.amazonfilters.com/case-study", "name" : "Case Studies" }, "position" : 2 }, { "@type" : "ListItem", "item" : { "@id" : "https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink", "name" : "Optimised Filtration of Pigmented Digital Ink" }, "position" : 3 } ] } ``` ```json { "@context" : "https://schema.org", "@id" : "#website", "@type" : "WebSite", "description" : "Industrial filtration solutions for pharmaceuticals, energy, water, food and beverage, and chemicals", "image" : "https://www.amazonfilters.com/hubfs/amz01/Global/Logos/amazon_filters_logo_color.svg", "inLanguage" : "en", "name" : "Amazon Filters", "potentialAction" : { "@type" : "SearchAction", "query-input" : "required name=search_term_string", "target" : { "@type" : "EntryPoint", "urlTemplate" : "https://www.amazonfilters.com/hs-search-results?term={search_term_string}" } }, "publisher" : { "@id" : "#organization" }, "url" : "https://www.amazonfilters.com/" } ``` ```json { "@context" : "https://schema.org", "@id" : "#organization", "@type" : "Organization", "address" : { "@type" : "PostalAddress", "addressCountry" : "GB", "addressLocality" : "Camberley", "addressRegion" : "Surrey", "postalCode" : "GU16 7PG", "streetAddress" : "Albany Park Estate, Frimley Road" }, "contactPoint" : { "@type" : "ContactPoint", "areaServed" : "GB", "availableLanguage" : "en", "contactType" : "customer service", "telephone" : "+44-1276-670600" }, "logo" : "https://www.amazonfilters.com/hubfs/amz01/Global/Logos/amazon_filters_logo_color.svg", "name" : "Amazon Filters", "sameAs" : [ "https://twitter.com/AmazonFilters", "https://www.linkedin.com/company/amazon-filters-ltd/", "https://www.facebook.com/AmazonFilters/" ], "url" : "https://www.amazonfilters.com/" } ``` ```json { "@context" : "https://schema.org", "@id" : "https://www.amazonfilters.com/optimised-filtration-of-pigmented-digital-ink#casestudy", "@type" : "CaseStudy", "about" : { "@type" : "Product", "name" : "SupaPleat Plus Ink" }, "client" : "Global Digital Ink Manufacturer", "description" : "A case study on the development of optimised filtration for pigmented digital ink to prevent printer nozzle blockage in industrial inkjet printing applications.", "image" : "https://www.amazonfilters.com/hubfs/amz01/Pages/Industry/digital-inks.jpg", "industry" : "Chemicals and Coatings", "location" : "UK", "name" : "Optimised Filtration of Pigmented Digital Ink", "outcome" : "Prevention of printer nozzle blockage; elimination of jetting issues; 34-38% reduction in particulate contamination; significant reduction in larger particles causing jetting failures" } ```
